    AC 220V 50Hz Digital Ground Resistance Tester For Power Industry

    RS2571 Digital Ground Resistance Tester


    Product Description

    The instrument applies to power industry, post and telecommunications, railway, communications, mining and other sectors to measure the grounding resistance of the various devices and the conductor resistance of low resistance; this instrument can also measure soil resistivity and ground voltage.


    Product Features


    1. 1) High-strength aluminum alloy shell body, the circuit equipped with phase locked loop and switched capacitor filter, based on which the instrument play an effective role in shielding power frequency and radio frequency interference.
    2. 2) DC/AC converter can transform DC current into AC low-frequency constant current for the measurement.
    3. 3) Auxiliary grounding resistance can change in the range of 0 ~ 2KΩ (RC), 0 ~ 40KΩ (RP), that will not affect measurement results.
    4. 4) Without manual adjustment to zero, with three and a half bits LED display, the instrument can be used for measuring the grounding resistance, the conductor resistance of low resistance, soil resistivity and AC ground voltage.
    5. 5) If tested loop encounter failure, the screen displays "1" indicating large range, which consistent with conventional measurement practices.

    Technical parameters
    Operating ConditionsTemperature0℃~+45℃
    Rellative Humidity≤85%
    Measuring RangeResistance0~2Ω(10mA)constant current value
    2~20Ω(10mA)
    20~200Ω(1mA)
    VoltageAC 0~19.99V
    Accuracy0~0.2Ω≤ ± 3% ± 1d
    0.2~199.9Ω≤±1.5%±1d
    1~19.99V≤±3%±1d
    Resolution0.001Ω,0.01Ω,0.1Ω,0.01V
    Power SupplyDC:8x1.5V(AA,R6) Battery
    AC:220V/50Hz
    Dimension220x200x105 mm
    Weight≤1.5kg
